Parameters
| Model Number | 230C-423kWh |
| Cathode Materials | LFP |
| Nominal Voltage | 614.4V |
| Nominal Capacity | 690Ah |
| Power Energy | 423.936kWh |
| Thermal Management | Heating Film+liquid cooling |
| Charging temperature | 0~60℃C |
| Operating Temperature(℃) | -30~60℃ |
| The charging ratio | 1C |
| The discharge rate | 1C |
| Weight | 2724.1±72KG |
| Cycle Life | ≥4000 |
| Protection Level | IP67 |
| Dimension (L*W*H) | 1060*630*240mm |
Why choose LGNE customized lithium battery?
Precisely match needs
customize capacity, voltage, shape and interface according to different application scenarios to ensure optimal adaptability
High energy density
adopt industry-leading battery tech-nology to provide longer battery life and higher power output
Intelligent BMS protection
with temperature control manage-ment, remote monitoring and fault warning functions to improve safety and reliability
Strong durability
through rigorous testing, adapt to extreme temperature, vibration and high load conditions, to ensure long-term stable operation
Green and environmentally friendly
zero emissions, low noise, to help global carbon neutrality goals
