H-PACK represents the heavy-duty end of LGNE's pack platform portfolio,
where physical size, mass and structural design scale with energy level, duty cycle and vibration exposure.
It is supplied as an integration-ready battery pack subsystem,
with clearly defined electrical, mechanical and thermal interfaces, enabling predictable integration into partner-defined system architectures.
System-level configuration, control strategies and application integration
are defined and implemented by the partners.
Parameters
| Model | H3-Pack | H5-Pack | H6-Pack |
| Cathode Materials | LFP | LFP | LFP |
| Nominal Voltage | 309.1V | 144.9V | 125.58V |
| Nominal Capacity | 324Ah | 324Ah | 324Ah |
| Power Energy | 101kWh | 46.94kWh | 40.68kWh |
| Thermal Management | Liquid cooling+heating | Liquid cooling+heating | Liquid cooling+heating |
| Charging temperature | 0~60℃ | 0~60℃ | 0~60℃ |
| Operating Temperature(℃) | -30~60℃ | -30~60℃ | -30~60℃ |
| The charging ratie | 1C | 1C | 1C |
| The discharge rate | 1C | 1C | 1C |
| Cycle Life | ≥4500 | ≥4500 | ≥4500 |
| Protection Level | IP68 | IP68 | IP68 |
| Dimension (L*W*H) | 2265 x 640 x 240mm | 1060 x 635 x 240mm | 950 x 635 x 250mm |
Other voltage platforms and energy configurations within the H-PACK platform are available upon request.
Why choose LGNE customized lithium battery?
Platform-based engineering
LGNE designs battery modules and packs as standardized platforms with defined mechanical, electrical and thermal interfaces, enabling predictable integration into OEM and system integrator architectures.
Engineering-to-production alignment
Design assumptions are developed in alignment with manufacturing constraints, ensuring consistency from prototype builds through controlled series production.
Series-ready manufacturing capability
LGNE's products are manufactured under controlled processes with defined tolerances and repeatable assembly, supporting stable quality across production batches.
Clear system responsibility boundaries
LGNE supplies integration-ready battery subsystems, while system-level configuration, control strategies and application integration remain with OEMs and system integrators.
Industrial-grade durability validation
Products are validated for vibration, thermal cycling and long-duty operation typical of off-highway, mining and commercial vehicle environments.
