Reliable Power for Low-Voltage Industrial Equipment
LGNE's 25.76V 173Ah LiFePO4 battery system delivers 4.45kWh of energy in a compact and robust package. It is designed for low-voltage industrial vehicles and equipment requiring reliable performance, long service life and flexible system integration.
Key Specifications
• Nominal Voltage: 25.76V
• Rated Capacity: 173Ah
• Nominal Energy: 4.45kWh
• Battery Chemistry: LiFePO4
• Battery Management System: Integrated BMS
Details
LGNE's 25.76V 173Ah LiFePO4 battery system provides 4.45kWh of reliable energy for low-voltage industrial equipment. The compact and robust design integrates BMS protection and supports flexible OEM integration.
Typical Applications
• Material handling equipment
• Automated guided vehicles (AGVs)
• Warehouse vehicles
• Other low-voltage industrial equipment
Key Features
• LiFePO4 chemistry for stable and reliable performance
• Integrated BMS for battery monitoring and protection
• Compact design for flexible equipment integration
• Support for customized mechanical and electrical interfaces
• Suitable for industrial applications
Integration Support
LGNE can provide engineering support for mechanical interfaces, electrical connections, communication protocols and application-specific parameters according to the customer’s equipment architecture and operating requirements.
Parameters
| Cathode Materials | Nominal Voltage | Nominal Capacity | Electric Energy | Thermal Management | Charging temperature | Operating Temperature(℃) | The charging ratio | The discharge rate | Weight | Cycle Life | Ingress Protection | Single package size |
| LFP | 25.76V | 173Ah | 4.456kWh | Heating Film | 0~60℃ | -30~60℃ | 0.5C | 1C | 50±3KG | ≥4000cycles | IP67 | 550*209*440 mm |
Why choose LGNE customized lithium battery?
Platform-based engineering
LGNE designs battery modules and packs as standardized platforms with defined mechanical, electrical and thermal interfaces, enabling predictable integration into OEM and system integrator architectures.
Engineering-to-production alignment
Design assumptions are developed in alignment with manufacturing constraints, ensuring consistency from prototype builds through controlled series production.
Series-ready manufacturing capability
LGNE's products are manufactured under controlled processes with defined tolerances and repeatable assembly, supporting stable quality across production batches.
Clear system responsibility boundaries
LGNE supplies integration-ready battery subsystems, while system-level configuration, control strategies and application integration remain with OEMs and system integrators.
Industrial-grade durability validation
Products are validated for vibration, thermal cycling and long-duty operation typical of off-highway, mining and commercial vehicle environments.
