Industrial Battery Platform for Compact Electric Loaders
LGNE's LFP lithium battery platform for compact electric loaders operates within a 72–150V architecture and is manufactured to support OEM- and integrator-defined system architectures, including drivetrain and hydraulic integration.
Designed for continuous load operation and dynamic working conditions, the platform ensures:
• Stable high-current discharge under hydraulic duty cycles
• Structural robustness against vibration and impact
• Reinforced enclosure for outdoor environments
• Standard communication compatibility within OEM and integrator systems
• Production-level consistency across batches
Parameters
| Cathode Materials | Nominal Voltage | Nominal Capacity | Electric Energy | Thermal Management | Charging temperature | Operating Temperature(℃) | The charging ratio | The discharge rate | Weight | Cycle Life | Ingress Protection | Single package size |
| LFP | 76.8V | 460Ah | 35.328kWh | Heating Film | 0~55℃ | -20~55℃ | 0.5C | 1C | 328KG | ≥4000Cycles | IP67 | 919*739*712.5mm |
Additional configurations available.
Why choose LGNE customized lithium battery?
Platform-based engineering
LGNE designs battery modules and packs as standardized platforms with defined mechanical, electrical and thermal interfaces, enabling predictable integration into OEM and system integrator architectures.
Engineering-to-production alignment
Design assumptions are developed in alignment with manufacturing constraints, ensuring consistency from prototype builds through controlled series production.
Series-ready manufacturing capability
LGNE's products are manufactured under controlled processes with defined tolerances and repeatable assembly, supporting stable quality across production batches.
Clear system responsibility boundaries
LGNE supplies integration-ready battery subsystems, while system-level configuration, control strategies and application integration remain with OEMs and system integrators.
Industrial-grade durability validation
Products are validated for vibration, thermal cycling and long-duty operation typical of off-highway, mining and commercial vehicle environments.
